Specification |
Unit |
CVS10 |
CVS12 |
CVS16 |
CVS20 |
CVS23 |
CVS32 |
|
Table diameter |
mm |
900 |
1000 |
1400 |
1800 |
2000 |
2500 |
|
Max. machining diamerer |
mm |
1000 |
|
|
|
|
3200 |
|
Max. machining diamerer of vertical tool post |
mm |
|
1250 |
1600 |
2000 |
2300 |
|
|
Max. machining diamerer of side tool post |
mm |
|
1100 |
1400 |
1800 |
2000 |
|
|
Max. height of workpiece |
mm |
800 |
1000 |
1200 |
1250 |
1250 |
1600/1800 |
|
Max. weight of workpiece |
t |
2 |
3.2 |
5 |
8 |
8 |
12 |
|
Table rotation range |
rpm |
8-250 |
6.3-200 |
5-160 |
4-125 |
3.2-100 |
2-63 |
|
Table speed steps |
step |
Stepless |
16 |
16 |
12 |
12 |
16 |
|
Feeding range |
mm/min |
0.8-86 |
0.8～86 |
0.8～86 |
0.8～86 |
0.8～86 |
0.8-86 |
|
Feeding steps |
step |
12 |
|||||
|
Horizontal travel of tool rest |
mm |
670 |
|
|
|
|
1800 |
|
Vertical travel of tool rest |
mm |
650 |
|
|
|
|
1000 |
|
Horizontal travel of vertical tool post |
mm |
|
700 |
915 |
1110 |
1210 |
|
|
Vertical travel of vertical tool post |
mm |
|
650 |
800 |
800 |
900 |
|
|
Horizontal travel of side tool post |
mm |
|
500 |
650 |
630 |
630 |
|
|
Vertical travel of side tool post |
mm |
|
900 |
1000 |
1100 |
1150 |
|
|
Travel of beam |
mm |
580 |
650 |
850 |
890 |
890 |
1000 |
|
Main motor power |
kW |
18.5 |
22 |
22 |
30 |
30 |
37 |
|
Overall dimension |
mm |
2187 |
2277 |
2662 |
3210 |
3235 |
4950 |
|
Weight |
t |
8.5 |
9.5 |
12.7 |
17.5 |
19.5 |
28 |
