Specification |
Unit |
CKVD40 |
CKVD50 |
CKVD50W |
CKVD63 |
CKVD63W |
CKVD80 |
|
|
Turning Range |
||||||||
|
Max. Turning Diameter |
mm |
4000 |
5000 |
5000 |
6300 |
6300 |
8000 |
|
|
Max. Machining Weight |
t |
63 |
100 |
160 |
||||
|
Max. Machining Height |
mm |
2500 |
3200 |
3200 |
4000 |
4000 |
5000 |
|
|
Table PaRameters |
||||||||
|
Table Diameter |
mm |
3600 |
4000 |
4500 |
5000 |
5700 |
6300 |
|
|
Table Rotary Speed |
Turning |
rpm |
0.5-50 |
0.4-40 |
0.32-32 |
|||
|
Milling |
rpm |
0.001-1 |
0.001-1 |
0.0008-0.8 |
||||
|
Max. Table Torque |
kNm |
125 |
200 |
320 |
||||
|
Cross Rail Head and Ram |
||||||||
|
Max. Turning Force |
kN |
63 |
80 |
100 |
||||
|
Ram Section Size |
mm |
250*250 |
300*300 |
300*300 |
||||
|
Ram Vertical Travel |
mm |
1600 |
2000 |
2000(2500) |
||||
|
Tools shank Section |
mm |
40*40 |
50*50 |
60*60 |
||||
|
Feed of Ram and Cross Rail Head |
mm/min |
0.1-1000 |
||||||
|
Rapid Speed of Ram and Cross Rail Head |
mm/min |
4000 |
||||||
|
Motor Power |
||||||||
|
Milling Spindle Motor Torque |
Nm |
560 |
940 |
940 |
||||
|
Milling Spindle Motor Power |
kW |
15 |
22 |
22 |
||||
|
Turning Motor Power |
kW |
75 |
100 |
100 |
||||
|
Other |
||||||||
|
Machine Weight(about) |
t |
90 |
140(170) |
190(260) |
||||
|
CNC Control System |
SIEMENS-802DSL/840DSL |
|||||||
|
Specification |
Unit |
CKVD80W |
CKVD100 |
CKVD100W |
CKVD120 |
CKVD125 |
CKVD125-1 |
|
|
Turning Range |
||||||||
|
Max. Turning Diameter |
mm |
8000 |
10000 |
10000 |
12000 |
12500 |
||
|
Max. Machining Weight |
t |
250 |
400 |
800 |
||||
|
Max. Machining Height |
mm |
5000 |
6300 |
5000/6300 |
8000 |
5000/6300 |
8000 |
|
|
Table PaRameters |
||||||||
|
Table Diameter |
mm |
7200 |
8000 |
8000 |
10000 |
10000 |
12000 |
|
|
Table Rotary Speed |
Turning |
rpm |
0.25-25 |
0.2-20 |
0.16-16 |
|||
|
Milling |
rpm |
0.00063-0.63 |
0.0005-0.5 |
0.0004-0.4 |
||||
|
Max. Table Torque |
kNm |
500 |
670 |
670/680 |
||||
|
Cross Rail Head and Ram |
|
|||||||
|
Max. Turning Force |
kN |
125 |
160 |
200 |
||||
|
Ram Section Size |
mm |
400*400 |
400*400 |
500*500 |
||||
|
Ram Vertical Travel |
mm |
2500(3200) |
3200(4000) |
3200(4000) |
||||
|
Tools shank Section |
mm |
70*70 |
80*80 |
100*100 |
||||
|
Feed of Ram and Cross Rail Head |
mm/min |
0.1-1000 |
||||||
|
Rapid Speed of Ram and Cross Rail Head |
mm/min |
4000 |
||||||
|
Motor Power |
||||||||
|
Milling Spindle Motor Torque |
Nm |
1200 |
3100 |
4700 |
||||
|
Milling Spindle Motor Power |
kW |
28 |
40 |
60 |
||||
|
Turning Motor Power |
kW |
125 |
140(160) |
140(160) |
||||
|
Other |
||||||||
|
Machine Weight(about) |
t |
260(320) |
450(650) |
650(8000) |
||||
|
CNC Control System |
SIEMENS-802DSL/840DSL |
|||||||
